Heavy Duty Torque Disc Hinge 0.1–15 N·m | 360° Hold
PRODUCT PARAMETERS
Description
Heavy-Duty Adjustable Torque Disc Hinge made of durable steel, delivering smooth 360° rotation with stable hold-at-any-angle performance. Torque is fully adjustable from 0.1 to 15 N·m, supporting both light and heavy loads. Ideal for industrial panels, equipment covers, enclosures, and machinery requiring precise positioning, high torque capacity, and long-term reliability in demanding environments.
Dimension Drawing
| Part Number | Material | Surface Finish | Torque (N·m) |
| HG11-135 | Iron | Nickel-Plated | 0.1 – 15 |
FAQ
What torque range does this hinge provide?
This hinge offers a wide adjustable range from 0.1 to 15 N·m. Therefore, it supports both lightweight panels and heavy-duty equipment covers with precise control.
Does it hold position at any angle?
Yes, it delivers smooth 360° rotation with stable hold-at-any-angle performance. As a result, panels and doors remain securely in place without additional supports.
How do I set the correct torque for my application?
First, evaluate panel weight, size, and mounting orientation. Then, adjust the torque accordingly to ensure controlled movement and reliable positioning during operation.
What applications is this hinge suitable for?
It is ideal for industrial panels, machinery covers, enclosures, and heavy equipment. In addition, it fits applications that require high torque capacity and precise positioning.
How does this hinge perform in demanding environments?
The steel construction ensures strength and durability. As a result, it withstands frequent use, maintains consistent torque output, and supports long-term performance in industrial conditions.
