Round Torque Hinge 360°, 1–10 N·m with 25 mm Cable Hole
PRODUCT PARAMETERS
Description
Round torque hinge made of durable iron with a 25 mm cable hole and 360° rotation. Adjustable torque from 1 N·m to 10 N·m ensures smooth, stable motion—ideal for control panels, equipment enclosures, and industrial displays.
Dimensional drawing
| Code | Item No. | Material | Surface Treatment |
| HG11-119 | HG11-119 | Iron | Nickel Plating |
FAQ
Do you support customization for this hinge?
Yes, in addition, we offer flexible customization, including torque range, cable hole size, dimensions, and surface finish based on your drawings or application needs.
What applications is it designed for?
Primarily, it is used in control panels, equipment enclosures, and industrial displays. At the same time, the 25 mm cable hole enables clean and efficient cable routing.
How does the adjustable torque work?
Specifically, the 1–10 N·m adjustable torque ensures smooth rotation. As a result, the hinge holds securely at any angle without unwanted movement.
How do you ensure product quality?
To ensure reliability, each hinge undergoes torque testing, cycle life testing, and corrosion resistance checks under strict quality control standards.
What about lead time and after-sales service?
In general, standard models ship quickly. Meanwhile, we provide responsive technical support and dependable after-sales service for all orders.
